ISO 8256 ASTM D256 Plastic Tensile Impact Test Machine Automatic Tensile Impact Tester Integrated Plastic Tensile Impact Tester

Large Image : ISO 8256 ASTM D256 Plastic Tensile Impact Test Machine Automatic Tensile Impact Tester Integrated Plastic Tensile Impact Tester

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	LONROY

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

ISO 8256 ASTM D256 Plastic Tensile Impact Test Machine Automatic Tensile Impact Tester Integrated Plastic Tensile Impact Tester

Description

Type:	Plastic Tensile Impact Testing Machine	Accuracy Class:	High Accuracy
Accuracy:	/	Customized Support:	OEM, ODM, OBM
Power:	/	Protection Class:	/
Voltage:	220 V, Other	Warranty:	1 Year
Highlight:	ISO 8256 plastic tensile impact tester , ASTM D256 tensile impact test machine , automatic plastic tensile impact tester

Products Description

ISO 8256 ASTM D256 Plastic Tensile Impact Test Machine Automatic Tensile Impact Tester Integrated Plastic Tensile Impact Tester

Product Introduction This instrument is a plastic tensile impact testing machine characterized by simple operation and high testing precision; it eliminates the need to disassemble fixtures or specimen holders. It is primarily used to determine the impact toughness of non-metallic materials such as rigid plastics, reinforced nylon, fiberglass (FRP), ceramics, cast stone, and electrical insulation materials. ISO 8256 ASTM D256 Plastic Tensile Impact Test Machine Automatic Tensile Impact Tester Integrated Plastic Tensile Impact Tester Reference Standards ISO 8256-2005: Plastics — Determination of tensile-impact strength ISO 179-2000: Plastics — Determination of Charpy impact properties JB/T 8762-1998: Plastics Charpy impact testing machine ISO 180-2000: Plastics — Determination of Izod impact strength JB/T 8761-1998: Plastics Izod impact testing machine ASTM D256-2010: Standard Test Methods for Determining the Izod Pendulum Impact Resistance of Plastics GB/T 13525-1992: Test method for tensile impact properties of plastics ISO 8256 ASTM D256 Plastic Tensile Impact Test Machine Automatic Tensile Impact Tester Integrated Plastic Tensile Impact Tester Product Features Integrated impact design; no need to disassemble fixtures or specimen holders. High-precision intelligent controller equipped with an LCD screen for intuitive and accurate data reading. Uses a carbon fiber pendulum rod to enhance material rigidity in the direction of impact and concentrate the impact mass at the pendulum's center of gravity, ensuring vibration-free impact testing and extended service life. Utilizes an imported high-resolution digital encoder for superior and stable angular measurement accuracy. Aerodynamically designed impact hammer and imported ball bearings significantly reduce mechanical friction loss. Automatic calculation of final results; stores up to 24 sets of test data and calculates the average value. Selectable Chinese/English operation interface; test results can be displayed in units such as J/m, kJ/m², kg-cm/cm, ft-lb/in, etc. Built-in micro-printer for printing test data. ISO 8256 ASTM D256 Plastic Tensile Impact Test Machine Automatic Tensile Impact Tester Integrated Plastic Tensile Impact Tester

ISO 8256 ASTM D256 Plastic Tensile Impact Test Machine Automatic Tensile Impact Tester Integrated Plastic Tensile Impact Tester

Specification

Technical Parameters

Name		Product Name	Plastic Tensile Impact Testing Machine
Model		Model	LR-1046
Performance Parameter	Pre-Swing Angle	150°
	Performance Parameter	Impact Energy	7.5J, 15J, 25J
	Performance Parameter	Impact Speed	3.8m/s
	Performance Parameter	Pendulum Center Distance	395mm
	Performance Parameter	Support Span	40mm, 60mm(62mm), 70mm, 95mm
	Performance Parameter	Impact Edge Radius	R=2mm±0.5mm
	Performance Parameter	Impact Edge Angle	30°±1°
Tensile impact properties	T-Type Head Mass	30g, 60g±1, 120g±1
Tensile impact properties	Sample Limit	Max Sample Thickness	4mm
Power Supply	Input Power	AC220V±10%, 50Hz
