JIS L1096 ASO M403 Leather Rubbing Tester 120 Times/Min 220V

Large Image : JIS L1096 ASO M403 Leather Rubbing Tester 120 Times/Min 220V

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	LONROY

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

JIS L1096 ASO M403 Leather Rubbing Tester 120 Times/Min 220V

Description

Voltage:	220V	Protection Class:	IP56
Test Speed:	120 Times Per Minute	Dimensions:	453750 Cm
Weight:	60 Kg	Power Supply:	AC 220V, 50Hz
Sample Load:	200g - 2000g	Fixture Width:	45mm
Maximum Fixture Spacing:	40mm	Fixture Spacing:	0 - 50mm (adjustable)
Surface Treatment:	American DuPont Powder	Curing Temperature:	200℃
Material:	Non-corrosive Structural Aluminum, Stainless Steel	Display Control:	LED-SLD806 Integrated Display
Drive Motor:	Precision Drive Motor
Highlight:	JIS L1096 leather rubbing tester , ASO M403 textile testing machine , 220V leather abrasion tester

JIS L1096 ASO M403 Leather Rubbing Resistance Testing Machine

Woven Materials Rubbing Tester

This rubbing test machine evaluates the resistance of leather and woven materials to back-and-forth rubbing. The sample is secured between fixtures, subjected to controlled pressure and motion for specified cycles, then assessed for damage.

Key Features

Tests leather and woven material durability through controlled rubbing cycles
American DuPont powder coating with 200℃ high-temperature curing for lasting finish
Constructed with corrosion-resistant aluminum and stainless steel components
Precision drive motor ensures smooth, quiet operation
LED-SLD806 integrated display with menu-driven controls
High-precision bearings for stable rotation and extended service life
One-touch automated testing with independent control

Compliance Standards

Meets GB/T 8948-2008, JIS L1096, K6404\ASO M403, ASO M403QB/1333-2018, QB/1618-2018, and QB/T 5246-2018 standards.

Technical Specifications

Parameter	Specification
Sample load	200g - 2000g (weight incremental loading)
Fixture width	45mm
Maximum fixture spacing	40mm
Adjustable fixture spacing	0 - 50mm
Test speed	120 cycles per minute
Dimensions	45×37×50 cm
Weight	Approximately 60 kg
Power Supply	AC 220V, 50Hz

JIS L1096 ASO M403 Leather Rubbing Resistance Testing Machine

Close-up view of testing machine components
