LONROY UV Curing System Ultraviolet Curing Machine Photocuring Equipment Ultraviolet Cure Device UV Irradiation Unit

Large Image : LONROY UV Curing System Ultraviolet Curing Machine Photocuring Equipment Ultraviolet Cure Device UV Irradiation Unit

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	LONROY

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

LONROY UV Curing System Ultraviolet Curing Machine Photocuring Equipment Ultraviolet Cure Device UV Irradiation Unit

Description

Type:	Testing Machine	Accuracy Class:	High Accuracy
Accuracy:	/	Application:	Lab Testing, Laboratory Testing
Customized Support:	OEM, ODM, OBM	Power:	/
Protection Class:	/	Voltage:	Other
Warranty:	1 Year

PRODUCT HIGHLIGHTS

High intensity UV LED light source, optional 365nm / 395nm, customizable 385nm and 405nm wavelengths
Knob power adjustment from 10% to 100%, flexible energy output matching different curing demands
0.5–8 m/min stepless conveyor speed adjustment, compatible with diversified production throughput
400mm wide high temperature resistant Teflon mesh belt, stable conveying and easy to clean
Forced air cooling system, effectively stabilize light source temperature and prolong service life
Long LED service life up to 20000 hours, reduce frequent lamp replacement cost
Uniform irradiation area of 400×100mm, consistent curing effect for flat workpieces
High precision P5 grade or higher bearings for smooth and low-noise belt operation
Stable UV energy output, test data traceable with EIT and Linshang energy meters
Compact overall structure, saves factory workshop space and easy for line integration
220V input voltage, simple wiring and convenient for on-site installation
Wide working ambient range from -10℃ to 50℃, adapts to various workshop environments
Suitable for UV glue, ink, coating curing for electronics, printing and new material industries
One year warranty period, reliable after-sales technical support provided
Mercury-free cold light source, eco-friendly and avoids thermal damage to heat-sensitive parts

LONROY UV Curing System Ultraviolet Curing Machine Photocuring Equipment Ultraviolet Cure Device UV Irradiation Unit

Technical Specifications

No.	Specification	Unit	Parameter
1	Model	/	LR-1401-B
2	Total Power	W	1200W
3	Power Adjustment	W	Knob adjustment (10–100%)
4	Dimensions	mm	1000 × 610 × 775
5	Irradiation Area	mm	400 × 100
6	Number of Light Sources	Set	1 set
7	Wavelength	nm	365nm/395nm (385nm/405nm customizable)
8	Irradiation Intensity	W/cm²	365nm: 900mW/cm² (50mm distance);
8	Irradiation Intensity	W/cm²		395nm: 1500mW/cm² (50mm distance)
9	LED Chip Brand	/	/
10	LED Lifespan	h	20,000h
11	Conveyor Width	mm	400mm
12	Conveyor Speed	m/min	0.5–8 m/min
13	Conveyor Material	/	Teflon mesh belt
14	Cooling Method	/	Forced air cooling
15	Input Power	V	220V
16	Ambient Conditions	/	Ambient temp: -10°C–50°C;
16	Ambient Conditions	/		Relative humidity: 25%–80% RH
17	Warranty Period	Year	One year

Key Components

No.	Item	Remarks
1	UV-LED Light Source	/
2	Power Supply	/
3	Main Electrical Components	/
4	Indicator Lights/Switches	/
5	Motor	/
6	Bearings	P5 Grade or higher

LONROY UV Curing System Ultraviolet Curing Machine Photocuring Equipment Ultraviolet Cure Device UV Irradiation Unit
