WAW-600 Hydraulic Servo Hydraulic Tensile Testing Machine Microcomputer-controlled Hydraulic Tensile Tester

Large Image : WAW-600 Hydraulic Servo Hydraulic Tensile Testing Machine Microcomputer-controlled Hydraulic Tensile Tester

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	LONROY
Model Number:	WAW-600

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

WAW-600 Hydraulic Servo Hydraulic Tensile Testing Machine Microcomputer-controlled Hydraulic Tensile Tester

Description

Maximum Compressive Space:	600mm(23.62in)	Maximum Tensile Space:	650 Mm(25.59in)
Type:	Hydraulic Tensile Testing Machine	Crossbeam Displacement Accuracy:	±0.1 Mm
Power Supply:	220 V	Product Name:	Hydraulic Servo Hydraulic Tensile Testing Machine
Model:	WAW-600	Max Load:	600KN
Host Weight:	5600 Kg
Highlight:	Hydraulic tensile testing machine with microcomputer control , Servo hydraulic tensile tester with warranty , WAW-600 hydraulic testing machine for tensile tests

WAW-600 Hydraulic Servo Hydraulic Tensile Testing Machine

WAW-600 microcomputer-controlled electro-hydraulic servo-hydraulic universal testing machine main machine adopts the structure of oil cylinder down type main machine, mainly used for the mechanical properties test of metal materials, non-metal materials, product parts, components, structural parts, standard parts and so on.
This series of testing machine can also do the material stretching, compression and bending test under the environment if it is equipped with an environmental device. For example high temperature tensile, low temperature tensile, compression and other tests.

WAW-600 Hydraulic Servo Hydraulic Tensile Testing Machine

Specification

Max Load	600KN
Test Error	≤1%
Test Range	Max Load 2%~100%
Clamping Method	Hydraulic Clamping
Diameter for Round	Φ13~Φ60 mm
Thickness for Flat	0~40mm
Width for Flat	80 mm
Max Tensile Space	650 mm
Max Compression Space	600 mm
Control Cabinet Size	1100(L)×620(W)×850(H) mm
Host Size	900(L)×750(W)×2300(H) mm
Power	2.3kw
Host weight	5600 kg
The clear spacing of columns	580 mm
Compression Plate Size	Φ205 mm
Span for Roller	450 mm
Roller Width	140 mm
Allowable Bending Length	100 mm
Max Piston Stroke	200 mm
Max Piston Speed	about 80 mm/min
Test Space Adjust Speed	about 150 mm/min
