ISO 9863 ASTM D5199 Geosynthetics Thickness Measuring Instrument Specified Pressure Geosynthetic Thickness Machine

Large Image : ISO 9863 ASTM D5199 Geosynthetics Thickness Measuring Instrument Specified Pressure Geosynthetic Thickness Machine

Product Details:

Place of Origin:	China
Brand Name:	Lonroy
Certification:	ISO ASTM CE

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotaible
Packaging Details:	Wooden package
Delivery Time:	5-8 work days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union
Supply Ability:	200

Contact Now

ISO 9863 ASTM D5199 Geosynthetics Thickness Measuring Instrument Specified Pressure Geosynthetic Thickness Machine

Description

Voltage:	220V	Protection Class:	Ip56
Work Pressure:	2 ± 0.01 KPa, 20 ± 0.1 KPa, 200 ± 1 KPa	Weight:	40kg
Dimensions:	600300400 Mm	Minimum Graduation Value:	0.001mm
Pressurization Method:	Mechanical Type	Measurement Range:	0.001 - 12 Mm
Pressing Foot Size:	2500mm²	Thickness Precision:	0.001mm
Pressure Accuracy:	±0.01 KPa, ±0.1 KPa, ±1 KPa	Display Type:	Numerical
Material:	Corrosion-resistant Coating	Level Adjustment:	Adjustable
Measurement Method:	Micrometer
Highlight:	Geosynthetics thickness tester 40kg , Textile testing machine ISO 9863 , Thickness tester ASTM D5199

ISO 9863 ASTM D5199 Geosynthetics Thickness Measuring Instrument

This precision instrument measures the thickness of various geosynthetics under specified pressure and time conditions. The sample is placed on the reference plate, and a circular pressure foot applies controlled pressure to measure the vertical distance between plates, with results expressed as average values.

Compliant Standards

GB/T 13761.1-2009, ISO 9863-1-2005, ASTM D5199-2001, JTG E50 T1112-2006, SL/T 235-5-2012

Key Features

Manufactured to meet all relevant standards and specifications
Corrosion-resistant outer shell with special surface coating
Precise mechanical pressure system for 2 KPa, 20 KPa, and 200 KPa applications
Adjustable level ensures uniform sample force application
Simple installation and operation
High-precision micrometer measurement
Clear numerical display for easy reading

Technical Specifications

Pressurization Method	Mechanical type
Measurement Range	0.001 - 12 mm
Minimum Graduation Value	0.001mm
Pressing Foot Size	2500mm²
Work Pressure	2 ± 0.01 kPa, 20 ± 0.1 kPa, 200 ± 1 kPa
Dimensions	600 * 300 * 400 mm
Weight	40kg

Product Images
