Measurement Parameters | |
Interfacial Tension Measurement Range | 10-6 ~ 100 mN/m |
Interfacial Tension Measurement Accuracy | 10-6 mN/m |
Inner-phase Volume Measurement Range | 0.1 μL ~ 10 μL |
Inner-phase Volume Measurement Accuracy | ≤0.1 μL |
Tension Measurement Method | AI measurement via CNN convolutional neural network standard object recognition model comparison |
Rotational Speed Control Parameters | |
Rotational Speed Control Range | 1000 ~ 12000 rpm |
Rotational Speed Control Accuracy | ± 1‰ |
Rotational Speed Control Mode | Stepless speed regulation |
Motor Type | Brushless DC motor |
Stable Centrifugal Field Essential Parameters | |
Rotating-shaft Coaxiality Tolerance | 2 μm |
Instrument Noise | < 55dB (Ambient temperature +5℃, at 5000rpm) |
Measuring Tube Vibration | < 0.05mm/s (at 5000rpm) |
Temperature Control Parameters | |
Temperature Control Range | 20℃ ~ 100℃ (no external temperature‑control device required) |
Temperature Display Resolution | ±0.1 ℃ |
Temperature Control Accuracy | ±1 ℃ |
Measurement Stage Control Parameters | |
Stage Angle Adjustment Range | ±20° |
Stage Angle Control Accuracy | ±0.05° |
Stage Level Control Mode | Manual control or AI automatic control |
Measuring Tube Parameters | |
Measuring Tube Inner Diameter | 2mm, 4mm |
Measuring Tube Sealing Method | Threaded drain sealing; one‑piece quick-connect end cap |
Leak-free Continuous Working Time (5000rpm) | 24 hours |
Measuring Tube End-cap Connection | One-piece quick-connect |
Imaging Functions | |
Imaging System | Dual-optical-path imaging: full-view optical path & patented local optical path |
Full-view Observation Length Range | 0-50 mm (full tube visible; no manual/electric lens zoom adjustment) |
Full-view Imaging Resolution | 1440 × 100 |
Local Observation Length Range | 0-4.4 mm (within measurement window) |
Local Imaging Resolution | 1440 × 1080 |
Image Sensor Type | CMOS |
Video Frame Rate | 50 fps |
Local Imaging Functions | Video recording & editing |
Full-view Imaging Functions | Video recording & editing |
Spinning-Drop Position AI Control Functions | |
Drop Position Control | Patented automatic locking & adjustment for spinning drop |
Spinning Drop Tracking | Automatic full-tube tracking and recognition |
AI Recognition Range for Drop Position | 0-50 mm |
AI Lock-control Range for Drop Position | 0-50 mm |
Drop Locking Mode | AI automatic locking |
Drop Adjustment Mode | AI-driven, synchronized with local camera position |
Max Travel for Drop Position Adjustment | 50 mm |
Local Camera Movement Range | 0-50 mm |
Sync Movement Speed | Low speed, High speed |
Sync Movement Mode | AI automatic synchronization |
Auxiliary Measurement Functions | |
Auxiliary Measurement | AI-assisted tension measurement by CNN recognition model |
Programmable Measurement | Custom combined sequences of speed, temperature and measurement cycles |
Data Synchronization | Real‑time data sync between instrument host and software |
Quick-access Image Windows | 30 sets |
Data Output | Auto-generate tension curves; auto-save results & drop images; review & edit historical data |
Report Export | Microsoft Word experiment report; Microsoft Excel measurement data export |
Other Parameters | |
Software Supported OS | Windows 10, Windows 11 |
Software Language | English, Chinese |
Remote Control | Support Windows, iOS, Android |
Communication Interface | USB 3.0 ×1 |
Operation Device | Laptop, mobile phone, iPad |
Overall Dimension | L×W×H 421mm×295mm×345mm |
Net Weight | 20kg (excluding accessories) |
Power Input | 100-240V, 50/60Hz |
Power Consumption | Rated 150W, Peak 210W |
