LRRY Products Thermal Analysis Comprehensive Analyzer Mineral Wool Thermal Behavior Tester

Description

Load Pressure:	490 Pa	Camera Resolution:	420 TV Lines
Heating Range:	RT To 1600°C	Displacement Range:	0–10 Mm
Warranty:	1 Year	Certification:	Includes Calibration Certification

LRRY Products Thermal Analysis Comprehensive Analyzer Mineral Wool Thermal Behavior Tester

1.Description:

This equipment can conduct three tests - thermal shrinkage temperature test of mineral wool and its products, sintering point test, and crystallization analysis - on the same device, achieving multi-functionality in one machine. It also includes automatic computer testing and data processing, automatically generating test reports and printing them out.

2.Configuration:

Including one test host, one electrical control cabinet, one software package, one quartz standard sample, and one computer.

3.Technical Parameter

Test Type / Parameter	Specification
Thermal Load Shrinkage Test
Heating Range	RT to 1600°C (0.1°C resolution), microcomputer programmable control
Displacement Range	0–10 mm (1 μm resolution)
Load Pressure	490 Pa
Control & Reporting	Computer automated control with automatic report generation
Compliance Standard	GB/T 11835-2007
Sintering Point Test
Purpose	Measures sintering temperature & refractoriness of molding materials, glass, ceramics. Enables clear observation of shrinkage, expansion, vitrification, spheroidization at high temps
Heating Range	RT to 1600°C (0.1°C resolution), microcomputer programmable control
Camera Resolution	420 TV lines
Control & Recording	Computer automated control with automatic image saving at temperature points
Crystallization Furnace
Heating Range	RT to 1600°C (0.1°C resolution), microcomputer programmable control
Control System	Fully automated computer temperature control
Compliance Standard	JC/T 750-1982 (1996) requirements for crystallization testing
