Uniaxial Modulus Tester for Inorganic Binder Stabilized Materials Civil Engineer 300kn Soil Compression Modulus Testing Machine

Large Image : Uniaxial Modulus Tester for Inorganic Binder Stabilized Materials Civil Engineer 300kn Soil Compression Modulus Testing Machine

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	LONROY

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

Uniaxial Modulus Tester for Inorganic Binder Stabilized Materials Civil Engineer 300kn Soil Compression Modulus Testing Machine

Description

Type:	Testing Machine	Accuracy Class:	High Accuracy
Accuracy:	±1.5%	Application:	Auto Testing, Laboratory Testing, Lab Testing
Customized Support:	OEM, OBM, ODM, Software Reengineering	Power:	/
Protection Class:	IP57	Voltage:	220 V
Warranty:	1 Year
Highlight:	Uniaxial Modulus Tester 300kN , Soil Compression Modulus Testing Machine , Inorganic Binder Stabilized Materials Tester

PRODUCT HIGHLIGHTS

Wide Load Capacity: Maximum load capacity of 300kN suitable for inorganic binder stabilized materials testing.
Comprehensive Control Modes: Supports constant force, constant deformation, and constant displacement control ranges from 0.5% to 100% F.S.
Digital Display & Control: Features computer control with digital display for real-time monitoring of test parameters.
Standard Compliance: Method complies with JJ GD50 Design Code for Asphalt Pavement of Highways for uniaxial compression modulus testing.
Fast Response Time: Average lead time within 15 workdays during both peak and off-peak seasons.
Flexible Payment Options: Accepts LC, T/T, D/P, Small-amount payment, Western Union, PayPal, and .
Global Shipping Terms: Supports FCA, FOB, EXW, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, and other Incoterms.

Uniaxial Modulus Tester for Inorganic Binder Stabilized Materials Civil Engineer 300kn Soil Compression Modulus Testing Machine

Scope of application Axial pressure is continuously and uniformly applied to the specimens of inorganic binder stabilized materials until the maximum force they can withstand is reached. During loading, an axial displacement sensor located in the middle section of the cylindrical specimen measures the axial deformation of this section. The uniaxial compression modulus of the specimen is determined based on the linear range of the stress-strain curve during the initial loading stage. This method complies with JJ GD50's' Design Code for Asphalt Pavement of Highways' for the testing of uniaxial compression modulus of inorganic binder stabilized materials.

Uniaxial Modulus Tester for Inorganic Binder Stabilized Materials Civil Engineer 300kn Soil Compression Modulus Testing Machine

Technical Specifications

Maximum load	300kN
Accuracy level	0.5
Measurement range	0.2%~100%F.S.(no step in the whole range)
Test force indication accuracy	±0.5%
Test force resolution	±500,000 m
Deformation measurement range (grating scale)	1%~100%F.S, maximum range 15mm
Transformation value accuracy (grid scale)	±0.5%
Resolution of deformation (stegol)	1μm
Accuracy of displacement indication	±0.3%
Displacement resolution	0.025μm
Force control rate regulation range	0.005~10%F·S/s
Force control rate control accuracy	when force control rate <0.05%F·S/s: ±0.5%; When the force control rate is greater than or equal to 0.05%F·S/s: ±0.3%
The range of variable rate adjustment	0.005~10%FS/s
Accuracy of strain rate control	elongation rate <0.05%F·S/s: ±0.5%; When the elongation rate is greater than or equal to 0.05%F·S/s: ±0.3%; Displacement rate adjustment range: 0.001~50mm/min (adjustable)
Displacement rate control accuracy	±0.2%
Constant force, constant deformation, constant displacement control range	0.5%~100%F·S
Constant force, constant deformation and constant displacement control accuracy	when the set value is less than 10%F·S/s: ±1%. When the set value is greater than or equal to 10%F·S/s: ±0.3%
