Wide Width Plasma AF Coating Machine Plasma AF Coater Lab 3-Axis Broad Format Nitrogen Plasma Nano Coating IR Curing Equipment

Large Image : Wide Width Plasma AF Coating Machine Plasma AF Coater Lab 3-Axis Broad Format Nitrogen Plasma Nano Coating IR Curing Equipment

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	LONROY

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

Wide Width Plasma AF Coating Machine Plasma AF Coater Lab 3-Axis Broad Format Nitrogen Plasma Nano Coating IR Curing Equipment

Description

Type:	Testing Machine	Accuracy Class:	High Accuracy
Accuracy:	±1.5%	Application:	Auto Testing, Laboratory Testing, Lab Testing
Customized Support:	OEM, OBM, ODM, Software Reengineering	Power:	/
Protection Class:	IP57	Voltage:	220 V, Other
Warranty:	1 Year
Highlight:	Wide Width Plasma AF Coating Machine , 3-Axis Broad Format Plasma Coater , Nitrogen Plasma Nano Coating Equipment

PRODUCT HIGHLIGHTS

Customizable Conveyor Width: Standard width is 800mm, with options for customization to meet specific production needs.
Dual Process Integration: Combines nitrogen plasma treatment and precision AF nano-coating in a single sequential workflow.
High Efficiency Cleaning: Delivers high cleanliness and excellent uniformity for mobile phones and electronic glass.
Flexible Control Mode: Operates via Industrial PC or Touch Screen for versatile user interaction.
Adjustable Flow Rate: Flow rate is adjustable, currently set at 0.4g/15s for precise coating application.

Wide Width Plasma AF Coating Machine Plasma AF Coater Lab 3-Axis Broad Format Nitrogen Plasma Nano Coating IR Curing Equipment

Product Introduction The LR-Z259 is a high-end AF (Anti-Fingerprint) wide-format plasma coating machine. It integrates two key components—a W800 wide-format nitrogen linear plasma system and an AF nano-precision spraying system—to execute two sequential processes: nitrogen plasma treatment and precision AF coating. Distinguished by high cleanliness, excellent uniformity, and high efficiency, the equipment is widely used in industries such as mobile phones, electronic glass for computers, and glass for home appliances. Applications This equipment is used in industries such as electronic glass and home appliance glass. Process Flow Wide-format nitrogen plasma cleaning + AF coating + IR curing.

Wide Width Plasma AF Coating Machine Plasma AF Coater Lab 3-Axis Broad Format Nitrogen Plasma Nano Coating IR Curing Equipment

Technical Specifications

Conveyor Width	W=800mm (Customizable)
Flow Rate	0.4g/15s (Adjustable)
Control Mode	Industrial PC or Touch Screen
Axis Quantity	3 Axes
Spray Gun Quantity	2 pcs
Wide Plasma Effective Width	800mm
Metering Pump	2 sets
Gas Type	N2, CDA
Wide Plasma Power	7.5KW
Effective Height	2～6mm
Air Pressure	0.6Mpa
Power Supply	380V, 10kw
Equipment Dimension	400022001850mm
