BEVS 1132U Intelligent Cone Plate Viscometer ISO 2884 ASTM D4287 High Shear Rate Tester Rheological Analyzer

The BEVS 1132U Intelligent Cone-Plate Viscometer is designed for testing micro-samples and temperature-sensitive materials. It provides stable temperature control and shear rate management, automatically measuring viscosity and outputting viscosity curves. This instrument is ideal for studying the effects of temperature and shear rate on fluid rheological properties, making it widely applicable in industrial quality control, process simulation, and preliminary screening of non-Newtonian fluid behavior.

• GB/T 9751.1 Paints and varnishes - Cone-plate viscometers operating at high shear rates
• ISO 2884-1 Paints and varnishes - Cone-plate viscometers operating at high shear rates
• ASTM D4287 Standard test method for determining high-speed shear viscosity using a cone-plate viscometer

A small sample is placed on a temperature-controlled plate. A drive motor rotates a conical rotor within the sample at a constant speed. The sample generates resistance against the rotor; the higher the viscosity, the greater the resistance. A torque sensor within the instrument measures this resistance and converts it into a viscosity value for display.

• 4.3-inch high-definition touchscreen display
• Automatic lifting system with high-precision DC motor
• Automatic temperature control plate, effectively avoiding temperature drift interference with viscosity data
• Equipped with five different rotors, covering an extremely wide viscosity measurement range
• Quick-release rotor structure, significantly improving efficiency
• Requires only a small sample size per test, especially suitable for precious formulations

• Supports Chinese/English languages
• Automatic lifting, automatic measurement, and automatic sample temperature control
• Settable rotation speed, start time, running time, and sample temperature
• Displays viscosity value, rotation speed, sample temperature, test status, and viscosity curve
• Automatically records and saves data
• Supports outputting test reports

Main Unit x1, Awl x1, Power Cord x1, Instruction Manual x1
