Product Details:
Place of Origin: Guangdong, China
Brand Name: LONROY
Payment & Shipping Terms:
Minimum Order Quantity: 1

Basket Mill Pigment Resin Dispersing Milling Machine Vertical 1.25L Liquids Agitator Sand Mill Coating Bead Grinding Equipment

Description
Type: Testing Machine Accuracy Class: High Accuracy
Accuracy: / Application: Auto Testing, Laboratory Testing, Lab Testing
Customized Support: OEM, ODM, OBM Power: ---
Protection Class: Ip56 Voltage: 220 V, Other
Warranty: 1 Year Instrument Weight: 35 Kg
Highlight:

Basket Mill pigment dispersing machine

,

Vertical resin sand mill

,

1.25L coating bead grinder

Basket Mill Pigment Resin Dispersing Milling Machine Vertical 1.25L Liquids Agitator Sand Mill Coating Bead Grinding Equipment



Basket Mill

The basket type sand mill is a high-performance product newly developed by our company, which integrates dispersion function and sand grinding function. The dispersion and sand grinding processes are completed by one machine in a container. It has functions of dispersion, refinement, and sand grinding, with high efficiency, good sand grinding fineness, and easy cleaning. Widely used for the dispersion, mixing, and grinding of materials in liquids used in experiments in factories, research institutions, universities, and medical institutions. The laboratory basket sand mill produced by our company has been widely used in fields such as pigments, inks, food, coatings, biology, physics and chemistry, cosmetics product development, and experimentation.



Basket Mill Pigment Resin Dispersing Milling Machine Vertical 1.25L Liquids Agitator Sand Mill Coating Bead Grinding Equipment

Technical Parameter

Motor power

370W 220V

Speed regulation range

130-3000r/min

Grinding basket size

Ø 80 x 60 mm

Dispersion disk diameter

Ø 60mm

Contact material material

SUS304

Lift stroke

260 mm

Recommended use of zirconium beads

Ø1.4-1.6mm (120g)

Bucket volume

1.2L

External dimensions

450*420*530mm

Instrument weight

35 kg









Basket Mill Pigment Resin Dispersing Milling Machine Vertical 1.25L Liquids Agitator Sand Mill Coating Bead Grinding EquipmentBasket Mill Pigment Resin Dispersing Milling Machine Vertical 1.25L Liquids Agitator Sand Mill Coating Bead Grinding EquipmentBasket Mill Pigment Resin Dispersing Milling Machine Vertical 1.25L Liquids Agitator Sand Mill Coating Bead Grinding Equipment
