Oxidative Self-heating Identification Machine Self-heating Substance Tester Fully Automatic Self-Heating Solid Test Apparatus

Large Image : Oxidative Self-heating Identification Machine Self-heating Substance Tester Fully Automatic Self-Heating Solid Test Apparatus

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	LONROY

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

Oxidative Self-heating Identification Machine Self-heating Substance Tester Fully Automatic Self-Heating Solid Test Apparatus

Description

Type:	Testing Machine	Accuracy Class:	High Accuracy
Accuracy:	/	Customized Support:	OEM, ODM, OBM
Power:	/	Protection Class:	/
Voltage:	220 V, Other	Warranty:	1 Year
Highlight:	self-heating identification machine fully automatic , self-heating substance tester lab equipment , self-heating solid test apparatus

Products Description

Oxidative Self-heating Identification Machine Self-heating Substance Tester Fully Automatic Self-Heating Solid Test Apparatus

Brief Description The Self-Heating Substance Tester determines whether a substance undergoes oxidative self-heating by placing it in a cubic wire-mesh container (with side lengths of 25 mm or 100 mm) and exposing it to air at temperatures of 100°C, 120°C, or 140°C. It complies with Test N.4 (Test method for self-heating substances) as specified in Section 33.3.1.6 of the Recommendations on the Transport of Dangerous Goods: Manual of Tests and Criteria, as well as GB/T 21612, Dangerous goods—Test method for self-heating of flammable solids Oxidative Self-heating Identification Machine Self-heating Substance Tester Fully Automatic Self-Heating Solid Test Apparatus Scope of application and standards 1) This tester measures the internal temperature of 100℃, 120℃, Exposure to air at 140°C determines whether a substance will self-heat by oxidation. 2) Comply with 33.3.1.6 Test N.4 of "Recommendation on the Transport of Dangerous Goods·Manual of Tests and Criteria": Self-heating Test methods for substances and GB/T 21612 "Dangerous Goods - Test Methods for Self-Heating of Flammable Solids". Oxidative Self-heating Identification Machine Self-heating Substance Tester Fully Automatic Self-Heating Solid Test Apparatus Functional features 1) The self-heating material tester uses an embedded processor and Windows CE operating system; 2) 8-inch LCD touch screen, which can display test status in real time; 3) Built-in hot air circulation heating system to ensure uniformity and stability of heating; 4) The digital PID algorithm accurately controls the heating temperature with high temperature control accuracy; 5) The test report includes the judgment of packaging type; 6) Automatic detection of instrument faults and sound and light alarm functions to ensure safer testing; 7) The test options are diversified, and users can configure corresponding test parameters according to the characteristics of the sample to realize any adjustment of the test sequence; 8) The mesh cage has special specifications and can be customized; 9) Display running time and real-time temperature in real time, automatically draw test curves, and view original data; 10) The front of the equipment is equipped with an explosion-proof glass observation window, and the back is designed with a pressure relief door. The internal thrust is greater than 2.5 kgf. Open the pressure relief door to ensure safer testing; 11) The test process is fully automated, without manual intervention, and supports functions such as parameter setting, data storage, and report viewing. Oxidative Self-heating Identification Machine Self-heating Substance Tester Fully Automatic Self-Heating Solid Test Apparatus

Oxidative Self-heating Identification Machine Self-heating Substance Tester Fully Automatic Self-Heating Solid Test Apparat

Specification

Technical indicators

No.	Technical Indicator Item	Specification Value
1	Working environment	5℃～30℃, <85%RH
2	Temperature control range	room temperature ~ 200℃
3	Temperature control accuracy	±1℃
4	Uniform temperature in the experimental area (below 140℃)	±1.5℃
5	Uniform temperature in the experimental area (140℃~180℃)	±2℃
6	Uniform temperature in the experimental area (180℃~200℃)	±2.5℃
7	Temperature measurement range	0～500℃
8	Temperature measurement resolution	0.1℃
9	Temperature measurement accuracy (below 300℃)	±2.5℃
10	Temperature measurement accuracy (above 300℃)	±(0.75% of reading)
11	Standard timing range	0～24h
12	Custom timing range	0～48h
13	Timing display resolution	1s
14	Cubic steel mesh container (small container)	side length 25mm, hole diameter 0.05mm
15	Small container cover	30mm×30mm×30mm
16	Cubic steel mesh container (large container)	side length 100mm, hole diameter 0.05mm
17	Large container cover	105mm×105mm×105mm
18	Cage size	150mm×150mm×250mm
19	Inner tank size	350mm×350mm×400mm

Our Advantages
