High Accuracy Balance Scale Laboratory Weighing Scale High-precision Weighing Balance High Accuracy Stability Weighing Equipment

Single weighing range

1-1000g

Weighing accuracy

±0.5g

Acceleration section dimension

350mm * 230mm (length * width)

Weighing section dimension

400mm * 230mm (length * width)

Rejection section dimension

600mm * 230mm (length * width)

Product dimensions (mm)

≤300 (length) × ≤230 (width) × (height)

Inspection speed

MAX 80 meters/minute or 100 pieces/minute (adjustable)

Division value

0.1g

Machine overall dimensions

1350 (length) × 650 (width) × 1300 (height) (mm)

Conveyor belt height from ground

700+50mm

Machine weight

Approximately 160 kg

Power requirements

Single-phase AC 220V ± 10% 50Hz/60Hz

Rejection method

Options include push rods, toggle levers, air blowing, falling, etc.

Pneumatic air supply requirements

0.6 - 1 Mpa, 8mm air hose

Frame material

Food-grade 304 stainless steel

Conveyor direction

Facing the operation interface, from left to right

Machine body material

Food-grade 304 stainless steel

Number of stored recipes

100 pieces, data can be exported to USB drive via USB

Communication support

RS232, 485 or Ethernet communication ports

Operating environment

Temperature: -5℃ to 40℃, humidity: 0 - 90% without condensation

Note: 1. The weighing accuracy is related to the product size, weight, condition, output, and the wind volume and vibration of the on-site environment;

2. The weighing speed is related to the measurement interval, length, and accuracy. The product spacing should be greater than one scale platform distance for the best result.
