EN 13286 ASTM D1883 California Bearing Ratio Test Machine CBR Tester BS 1377 AASHTO T193 Soil CBR Testing Equipment

Large Image : EN 13286 ASTM D1883 California Bearing Ratio Test Machine CBR Tester BS 1377 AASHTO T193 Soil CBR Testing Equipment

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	LONROY

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

EN 13286 ASTM D1883 California Bearing Ratio Test Machine CBR Tester BS 1377 AASHTO T193 Soil CBR Testing Equipment

Description

Type:	Testing Machine	Accuracy Class:	High Accuracy
Accuracy:	/	Application:	Auto Testing
Customized Support:	OEM, ODM, OBM	Power:	---
Protection Class:	Ip56	Voltage:	220 V
Warranty:	1 Year	Standard:	BS 1377-4, EN 13286-47, ASTM D 1883, AASHTO T 193
Highlight:	California Bearing Ratio Test Machine , CBR Tester ASTM D1883 , Soil CBR Testing Equipment BS 1377

EN 13286 ASTM D1883 California Bearing Ratio Test Machine CBR Tester BS 1377 AASHTO T193 Soil CBR Testing Equipment

Product Introduction

Bearing ratio (CBR) tester is used for carrying out bearing ratio tests on various soil and pavement base and underlying materials after making specimens in the specified test cylinder.

Standard

BS 1377-4, EN 13286-47, ASTM D 1883, AASHTO T 193 Bearing ratio (CBR) tester is used for carrying out bearing ratio tests on various soil and pavement base and underlying materials after making specimens in the specified test cylinder. The maximum particle size of the mixture should be controlled within 25mm and not more than 40mm.

EN 13286 ASTM D1883 California Bearing Ratio Test Machine CBR Tester BS 1377 AASHTO T193 Soil CBR Testing Equipment

Technical Specification

Standard	BS 1377-4, EN 13286-47, ASTM D 1883, AASHTO T 193
Capacity	50 KN
Speed	1 mm/min / 1.27 mm/min (adjustable)
Fast speed	15 mm/min
Penetration bar	Diameter 50 mm × 100 mm
Displacement sensor	0-25.00 mm / 0.001 mm resolution
Multi-orifice	2 PCS
Loading plate	4 PCS (OD 150 mm, ID 52 mm, weight 1.25 KG/PC)
Cylinder mould	ID 152 mm × 170 mm
Power	220 V
