Single-Lever Consolidation Tester Soil Compression Testing Equipment Direct Shear Tester Compression Coefficient Test Machine

Large Image : Single-Lever Consolidation Tester Soil Compression Testing Equipment Direct Shear Tester Compression Coefficient Test Machine

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	LONROY

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

Single-Lever Consolidation Tester Soil Compression Testing Equipment Direct Shear Tester Compression Coefficient Test Machine

Description

Type:	Testing Machine	Accuracy Class:	High Accuracy
Accuracy:	/	Application:	Auto Testing
Customized Support:	OEM, ODM, OBM	Power:	---
Protection Class:	Ip56	Voltage:	220 V
Warranty:	1 Year	Load Arm Ratios:	12:1, 10:1
Instrument Structure:	Steel Structure
Highlight:	Single-Lever Consolidation Tester soil compression , Direct Shear Tester compression coefficient , Soil Compression Testing Equipment lab machine

Single-Lever Consolidation Tester Soil Compression Testing Equipment Direct Shear Tester Compression Coefficient Test Machine

Description

This product is used for soil compression tests to determine the relationship between soil deformation and pressure, or void ratio and pressure, and the relationship between deformation and time. This allows for the calculation of unit settlement, compression coefficient and index, rebound index, compression modulus, consolidation coefficient, etc. The specific tests performed depend on the engineering requirements. (Standard: 50123-2019 GB /T0137-1993)

Single-Lever Consolidation Tester Soil Compression Testing Equipment Direct Shear Tester Compression Coefficient Test Machine

Technical Specification

Sample area	30cm², 50cm²
Medium pressure range	30cm² (12.5-1600) KPa 50cm² (12.5-800) KPa
Lever ratios	1:12, 1:10
Load pressure	12.5Kpa-1600Kpa/30cm² 12.5Kpa-800Kpa/50cm²
Load arm ratios	12:1, 10:1
Consolidated container	1×beam, 2×beam, 3×beam
Instrument structure	Steel structure
