Ultraviolet Irradiation Detector Insulated Glass UV Radiation Tester Glass Ultraviolet Radiation Resistance Testing Machine

Large Image : Ultraviolet Irradiation Detector Insulated Glass UV Radiation Tester Glass Ultraviolet Radiation Resistance Testing Machine

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	LONROY

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

Ultraviolet Irradiation Detector Insulated Glass UV Radiation Tester Glass Ultraviolet Radiation Resistance Testing Machine

Description

Power:	1.8KW	Voltage:	220 V
Protection Class:	Ip56	Test Chamber Temperature:	50℃ ± 3℃
Test Light Source:	UV Lamp MLU Type 300W	Time Setting Range:	0 - 300h
Cooling Plate Material:	Copper	Light Output Power:	> 40W / M²
Sample Distance:	300mm	Inlet Water Temperature:	16℃ ± 2℃
Outlet Water Temperature:	16℃ ± 2℃	Working Temperature:	Not Lower Than 20℃
Equipment Composition:	UV Irradiation Detector And Constant Temperature Circulating Water Device	Water Supply Requirement:	Not Required
Power Supply:	AC: 220V / 1.8KW
Highlight:	UV Lamp MLU Type 300W UV Radiation Tester , 50℃ ± 3℃ Test Chamber Temperature Insulated Glass Testing Machine , 0 - 300h Time Setting Range Ultraviolet Irradiation Detector

Ultraviolet Irradiation Detector Insulated Glass UV Radiation Tester Glass Ultraviolet Radiation Resistance Testing Machine

Product Description

Product Introduction

The ultraviolet irradiation detector is designed and manufactured in accordance with the technical requirements of the national standard GB/T11944-2012 "Insulated Glass". It is a testing equipment used to examine the ultraviolet radiation resistance of insulating glass.

Working principle

Ultraviolet lamps are installed in a sealed test chamber. The glass sample is placed in an appropriate position within the chamber and exposed to ultraviolet radiation. A cooling plate is placed closely against the other side of the sample, and the cooling plate is cooled by tap water. During the test, it is checked whether fog, oil or other contaminants appear on the cooling plate after the insulating glass is exposed to ultraviolet radiation, in order to determine the insulating glass's resistance to ultraviolet radiation.

Ultraviolet Irradiation Detector Insulated Glass UV Radiation Tester Glass Ultraviolet Radiation Resistance Testing Machine

Technical Specification

Temperature inside the test chamber	50℃ ± 3℃
Power supply / power	AC: 220V / 1.8KW
Cooling plate material	Copper
Light output power	> 40W / m²
Distance between sample center and light source	300mm
Test light source	UV lamp MLU type 300W
Inlet and outlet water temperature of the cooling plate	16℃ ± 2℃
Time setting range	0 - 300h
Working environment temperature	Not lower than 20℃
Equipment composition	Consists of a UV irradiation detector and a constant temperature circulating water device
Note	This equipment does not require an inlet and outlet water supply
