Automatic Polarimeter Optical Rotation Instrument Polarimetry Apparatus Self Automated Optical Rotation Meter

Large Image : Automatic Polarimeter Optical Rotation Instrument Polarimetry Apparatus Self Automated Optical Rotation Meter

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	LONROY

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

Automatic Polarimeter Optical Rotation Instrument Polarimetry Apparatus Self Automated Optical Rotation Meter

Description

Accuracy:	0.01 Grade	Power:	250W
Voltage:	220 V	Net Weight:	28 Kilograms
Light Source:	LED Cold Light Source	Working Wavelength:	589.3nm / 546nm
Measurement Range:	±90° (optical Rotation), ±259°Z (specific Gravity)	Resolution:	0.0001° (optical Rotation)
Indication Error:	±0.002°	Repeatability:	0.002° (standard Deviation S)
Temperature Control Range:	10°C - 60°C	Temperature Control Accuracy:	±0.01°C
Display Mode:	10-inch TFT Touch Screen	Test Tube:	200mm, 100mm Standard, 100mm Temperature-controlled
Data Storage:	64G
Highlight:	0.01 grade accuracy Automatic Polarimeter , 10-inch touch screen Optical Rotation Meter , 64G measurement database Polarimetry Apparatus

Automatic Polarimeter Optical Rotation Instrument Polarimetry Apparatus Self Automated Optical Rotation Meter

Product Description

Innovation Points

1. Built-in Peltier temperature control enhances accuracy and stability.

2: Includes optical rotation / specific rotation / concentration / sugar content and custom mode;

3: LED cold light sources replace traditional sodium lamps and halogen tungsten lamps;

4: Compliant with 21 CFR Part 11 audit trails, pharmacopoeia and electronic signatures;

5: Supports network printing and data statistics and retrieval;

6: Multi-level permission management, with permissions freely configurable;

7: 10-inch touch screen with a user-friendly interface;

8: The system comes with an automatic calibration system.

Automatic Polarimeter Optical Rotation Instrument Polarimetry Apparatus Self Automated Optical Rotation Meter

Technical Specification

Measurement Mode	Optical rotation, specific rotation, concentration, sugar content / custom
Light Source	LED cold light source + high-precision interference filter
Working Wavelength	589.3nm / 546nm
Testing Functions	Single measurement, multiple measurements, continuous measurement mode
Measurement Range	Optical rotation ±90°, Specific gravity ±259°Z
Resolution	0.0001° (for optical rotation)
Indication Error	±0.002°
Repeatability	(Standard deviation s) 0.002° (for optical rotation)
Temperature Control Range	10°C - 60°C (Peltier)
Temperature Control Accuracy	±0.01°C
Display Mode	10-inch TFT true-color touch screen
Test Tube	200mm, 100mm standard type, 100mm temperature-controlled type
Transmittance	0.01%
Automatic Calibration	Yes / Standard tube
User Management	Available / Four-level permission management
Communication Interface	USB connection, RS232 connection, VGA, Ethernet; USB/keyboard/mouse/general printer/VGA/ethernet
Data Storage	64G
Audit Trail	Yes
Method Library	Yes
Electronic Signature	Yes
Pre-storage Measurement Method	Yes
Measurement Database	64G
Multifunctional Search	Yes
Custom Formula Editing	Yes
Exportable File Formats	PDF and Excel
WIFI Printing	Yes
Cloud Service	Yes
Operating System	Equipped
Language	Chinese / English
High-level Protection MD5 Verification (for Exported Files)	Yes
User Classification and Permission Settings	4 levels
User Login Password Protection	Yes
Modify Date and Time Tracking	Yes
Instrument Accuracy	0.01 grade
Printer	Wireless Printer
Power Supply	220V ± 22V, 50Hz ± 1Hz, 250W
Net Weight of the Instrument	28 kilograms
Standard Configuration	50mm micro temperature-controlled 0.8ml test tube, 100MM temperature-controlled test tube, 200MM temperature-controlled test tube, regular glass tubes of 100MM and 200MM
Other Optional Accessories	Mouse, keyboard connection, universal printer / wireless network printer
