ISO 2813 ASTM D523 Triangular Haze Gloss Meter Tri-angle Haze Gloss Testing Instrument

Large Image : ISO 2813 ASTM D523 Triangular Haze Gloss Meter Tri-angle Haze Gloss Testing Instrument

Product Details:

Place of Origin:	China
Brand Name:	Lonroy
Certification:	ISO ASTM CE

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotaible
Packaging Details:	Wooden package
Delivery Time:	5-8 work days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union
Supply Ability:	200

Contact Now

ISO 2813 ASTM D523 Triangular Haze Gloss Meter Tri-angle Haze Gloss Testing Instrument

Description

Voltage:	220V	Protection Class:	IP56
Operating Temperature:	15 - 40°C (60 - 104°F)	Operating Humidity:	Up To 85% Without Fogging
Dimensions:	65mm X 140mm X 50mm	Weight:	530g
Measurement Angles:	20°, 60°, 85°	Measurement Area 20°:	6mm X 6mm
Measurement Area 60°:	6mm X 12mm	Measurement Area 85°:	4mm X 45.9mm
Power Supply:	Rechargeable Lithium Battery	Continuous Working Time:	17 Hours
Reading Capacity:	Over 10,000 Readings	Memory Capacity:	8MB (approx. 2,000 Readings)
Charging Duration:	4 Hours
Highlight:	3-angle haze gloss meter 220V , ISO 2813 gloss meter 530g , ASTM D523 textile testing machine

ISO 2813 ASTM D523 Triangular Haze Gloss Meter

The Tri-angle Haze Gloss Tester is a precision measuring instrument that complies with ISO 2813 and ASTM D523 standards, featuring three measurement angles for comprehensive surface gloss analysis.

Product Introduction

This gloss meter measures surface gloss in Gloss Units (GU), traceable to international reference standards from BAM (Germany), NRC (Canada), and NPL (UK). The three measurement angles provide optimal resolution for different surface types:

60° angle: Standard measurement for all surfaces, used as reference for other angles
85° angle: Recommended for low-gloss surfaces (when 60° measurement is <10GU)
20° angle: Ideal for high-gloss surfaces (when 60° measurement is >70GU), particularly sensitive to surface fogging

Product Features

Full-color screen with adjustable brightness
6 touch keys for intuitive operation
Calibration base with positioning detection
One-button measurement of all parameters
Fast measurement capability
Customizable batch names for measurement results

Technical Specifications

Measurement Parameters	Maximum/minimum value, average value, standard deviation, all measurement parameters
Analysis Function	Built-in trend analysis, gloss value
Power Supply	Rechargeable lithium battery (17 hours continuous operation)
Memory Capacity	8MB (approximately 2,000 readings)
Data Transmission	Bluetooth, USB (PC/MAC compatible, no software required)
Dimensions & Weight	65mm * 140mm * 50mm, 530g
Supported Languages	Chinese, English, French, German, Spanish, Italian, Japanese, Turkish
Measurement Areas	20°: 6mm * 6mm 60°: 6mm * 12mm 85°: 4mm * 45.9mm
Operating Conditions	Temperature: 15-40°C (60-104°F) Humidity: Up to 85% (non-condensing)
