FTTS FA019 FZT 73067 Fabric Contact Coolness Tester Textiles Thermal Conductivity Testing Machine

FTTS FA019 FZT 73067 Fabric Contact Coolness Tester Textiles Thermal Conductivity Testing Machine
FTTS FA019 FZT 73067 Fabric Contact Coolness Tester Textiles Thermal Conductivity Testing Machine FTTS FA019 FZT 73067 Fabric Contact Coolness Tester Textiles Thermal Conductivity Testing Machine FTTS FA019 FZT 73067 Fabric Contact Coolness Tester Textiles Thermal Conductivity Testing Machine FTTS FA019 FZT 73067 Fabric Contact Coolness Tester Textiles Thermal Conductivity Testing Machine FTTS FA019 FZT 73067 Fabric Contact Coolness Tester Textiles Thermal Conductivity Testing Machine

Large Image :  FTTS FA019 FZT 73067 Fabric Contact Coolness Tester Textiles Thermal Conductivity Testing Machine

Product Details:
Place of Origin: China
Brand Name: Lonroy
Certification: ISO ASTM CE
Model Number: LR-A119
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotaible
Packaging Details: wooden package
Delivery Time: 5-8 work days
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 200

FTTS FA019 FZT 73067 Fabric Contact Coolness Tester Textiles Thermal Conductivity Testing Machine

Description
Product Name: Fabric Contact Coolness Tester Power Supply: 220V, 50Hz, 150W
Warranty: 1` Year Printer Interface: With Printer Interface
Test Duration: Adjustable From 0.1 Seconds To 99999.9 Seconds Heating Plate Temperature Range: Room Temperature + 5℃ To 48℃
Highlight:

FZT 73067 Thermal Conductivity Tester

,

Thermal Conductivity Testing Machine

,

Textiles Thermal Conductivity Testing Machine

FTTS FA019 FZT 73067 Fabric Contact Coolness Tester Textiles Thermal Conductivity Testing Machine

Introduction

The textile contact instant cooling sensation tester is used to measure the cooling effect of pajamas, bedding, fabrics, and underwear, and it can also measure the thermal conductivity.



Compliant with standards

Standards such as GB/T 35263-2017, FTTS-FA-019, and FZT 73067-2020.



Test principle

Under the specified test environment conditions, the thermal detection plate with a higher temperature than the sample is brought into contact with the sample, and the change in the temperature of the thermal detection plate over time is measured. The contact cooling sensation coefficient (qmax) is calculated from this, which can characterize the cooling sensation performance of the sample at the contact moment. A larger qmax value indicates a stronger sensation of cooling by the skin, while a smaller value indicates a weaker sensation of cooling by the skin.



Technical Characteristics

1. The surface of the instrument is coated with high-quality electrostatic paint, which is durable and long-lasting.

2. The panel is made of imported special aluminum.

3. Desktop model, equipped with high-quality feet.

4. Some exposed parts are made of imported special aluminum.

5. The color touch screen provides a beautiful and elegant display. It features a menu-based operation mode, offering a level of convenience comparable to that of a smart phone.

6. The core control components are equipped with the 32-bit multi-functional motherboard from STMicroelectronics.

7. Automatic testing, automatic calculation of test results.

8. The heating plate and the heat detection plate both utilize high-precision sensors.


Technical Specification

Heating plate temperature range

Room temperature + 5℃ to 48℃

Temperature display resolution of the heating plate, heat detection plate, and sample loading platform

0.1℃

Response time of the thermal detection board

< 0.2 seconds

Test duration

Adjustable from 0.1 seconds to 99999.9 seconds

Temperature range of the low-temperature constant temperature bath

-5℃ to 90℃

Software control and test curves

Online software control, real-time test curves

Printer interface

With printer interface

Power supply

220V, 50Hz, 150W
