Fabrics Rolling Friction Electrostatic Properties Testing Machine Textiles Friction Test Device

Large Image : Fabrics Rolling Friction Electrostatic Properties Testing Machine Textiles Friction Test Device

Product Details:

Place of Origin:	China
Brand Name:	Lonroy
Certification:	ISO ASTM CE
Model Number:	LR-A138

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotaible
Packaging Details:	wooden package
Delivery Time:	5-8 work days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union
Supply Ability:	200

Contact Now

Fabrics Rolling Friction Electrostatic Properties Testing Machine Textiles Friction Test Device

Description

Product Name:	Roller Friction Machine	Inner Lining Material Of The Drum:	Nylon, Polypropylene Standard Fabric
Customization:	Available	Heating Method:	Electrical Warm Air Method
Depth Of The Drum:	≥ 350mm	Inner Temperature Of The Drum:	60 ± 10 ℃
Highlight:	Rolling Friction Electrostatic Properties Testing Machine , Electrostatic Rolling Friction Testing Machine , Textiles Rolling Friction Testing Machine

Fabrics Rolling Friction Electrostatic Properties Testing Machine Textiles Friction Test Device

Purpose

The electrostatic properties of fabrics after being charged through the rolling friction process.

Compliant with standards

GB/T12703.3-2009, etc.

Instrument characteristics

1. Apply the specified friction material to the sample, causing it to become charged. Then, measure the charge of the sample after it is inserted into the Faraday cylinder, and convert it into the charge per unit area.

2. The measuring device consists of a friction device and a potential measurement device.

3. The potential measurement device consists of a Faraday cylinder, a capacitor and a voltmeter.

Technical Specification

Inner diameter of the drum	≥ 460mm
Diameter of the drum	≥ 280mm
Depth of the drum	≥ 350mm
Rotation speed of the drum	≥ 45r/min
Number of drum blades	3
Inner lining material of the drum	Nylon, polypropylene standard fabric
Heating method	Electrical warm air method
Exhaust volume	≥ 2m³/min
Operating time	Adjustable from 0 to 99.99 minutes
Inner temperature of the drum	60 ± 10 ℃
The sample inlet and outlet areas	Covered with double-sided adhesive tape
