High Temperature test Chamber Drying Oven

High temperature test chamber  drying oven

use

It is mainly used for high temperature test, drying, baking and disinfection of non-volatile and non-flammable and explosive products. It can also be used for general constant temperature test work. It is a necessary equipment for laboratories and scientific research institutions.

High temperature test chamber  drying oven

This product has the following characteristics:

 Adopt block assembly structure, surface using epoxy powder electrostatic spraying process;

Adopt digital display, digital setting temperature, can reduce the visual reading error and operation error;

 With independent over temperature protection, over current protection and other functions.

Balanced temperature control system (BTC) + specially designed fan forced air circulation system, based on P.I.D.The method controls SSR, so that the heat added to the system is equal to the heat loss, so it can be used stably for a long time.

At room temperature 25℃, no load

Configuration list:

1.Contactor: Taiwan.

2. Thermal relay: Taiwan.

3. Temperature controller: Taiwan.

4. Overtemperature Protector: Taiwan.

5. No fuse switch: Taiwan.

6. Solid State Relay: Taiwan

7. Switch button: Taiwan.

8. Dry Burn Protector: Italy.

High temperature test chamber  drying oven

Controller Introduction:

Temperature to time, when to stop, buzzer prompt.

1. Temperature controller: LED dual number display button PID temperature controller table.

2.Controller Specification:

 Precision: Temperature: ±0.3%1digit F.S.

 Resolution: Temperature: ±0.1.

 With upper and lower limit standby and alarm function.

 A variety of temperature input signal selection.

 P.I.D control parameter setting and P.I.D automatic calculation.

3. Screen display function:

 key input data.

 Display temperature setting (SV) and actual (PV) values directly.

 Large seven-segment LED high brightness display SV, PV and various parameters.
