High Quality Carbon Black Content Tester/Carbon Black Content Testing Machine/ Carbon Black Content Analyzer

Large Image : High Quality Carbon Black Content Tester/Carbon Black Content Testing Machine/ Carbon Black Content Analyzer

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	LONROY

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

High Quality Carbon Black Content Tester/Carbon Black Content Testing Machine/ Carbon Black Content Analyzer

Description

Type:	Testing Machine	Protection Class:	IP57
Voltage:	220 V, 380 V	Display Mode:	LCD Display
Furnace Size:	φ 31×350±5 Mm	Heating Element:	High-temperature Alloy Wire
Heating Zone Length:	200 Mm	Constant Temperature Zone:	150 Mm
Operating Temperature:	Room Temperature ~ 1050℃	Temperature Control:	Intelligent Programmable Control
Power Supply:	AC220V/50HZ	Sensor Sensitivity:	0.1℃
Air Path Control:	Two Paths
Highlight:	carbon black content tester machine , carbon black analyzer thermal , carbon black testing equipment

High Quality Carbon Black Content Tester/Carbon Black Content Testing Machine/Carbon Black Content Analyzer

This instrument is designed for determining carbon black content in cable and optical cable insulation, sheath materials, plastic pipes, plastic particles, and masterbatch. Using gravimetric analysis of samples decomposed at high temperature under nitrogen protection, it provides accurate measurements with easy operation and reliable performance. Carbon black content significantly affects material properties including hardness, elasticity, wear resistance, and insulation.

Compliance Standards

ISO 6964, GB/T 13021, IEC 60811-4-1, GB/T 2951.41, JTG E50 T1165, ASTM D1603-2012, CJ/T 125-2000, GB/T2951.41-2008 (not limited to these standards)

Technical Specifications

Parameter	Specification
Display Mode	LCD display
Furnace Size	φ 31×350±5 mm
Heating Element	High-temperature alloy wire
Heating Zone Length	200 mm
Constant Temperature Zone Length	150 mm
Operating Temperature	Room temperature ~ 1050℃
Temperature Control Mode	Intelligent programmable control
Power Supply	AC220V/50HZ (customizable)
Sensor Sensitivity	0.1℃
Air Path Control	Two paths
