LRR-DW Low Temperature Automatic Calorimeter Thermal Analyzer

I'm Online Chat Now

LRR-DW Low Temperature Automatic Calorimeter Thermal Analyzer

LRR-DW Low Temperature Automatic Calorimeter Thermal Analyzer
LRR-DW Low Temperature Automatic Calorimeter Thermal Analyzer LRR-DW Low Temperature Automatic Calorimeter Thermal Analyzer

Large Image :  LRR-DW Low Temperature Automatic Calorimeter Thermal Analyzer

Product Details:
Place of Origin: China
Brand Name: Lonroy
Certification: CE ISO ASTM
Model Number: LRR-DW
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotaible
Packaging Details: wooden package
Delivery Time: 5-8 work days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 200

LRR-DW Low Temperature Automatic Calorimeter Thermal Analyzer

Description
Sample Dimensions: Ø30 × 80 Mm Power Supply: 220V / 50Hz
Heat Capacity Range: 0.05 - 5 KJ/(kg·K) Accuracy: ≤1% ±0.002
Warranty: 1 Year Certification: Includes Calibration Certification
Highlight:

automatic thermal analyzer

,

220v thermal analyzer

,

220v automatic calorimeter

LRR-DW Automatic Low-Temperature Calorimeter Thermal Analyzer

1.Description:

This instrument is designed and manufactured in accordance with GJB 330A-2000 Solid Materials 60-273K Specific Heat Capacity Test Method (60-373K Isolated Method). All measurements and controls are carried out using computer control, reducing human errors and improving test accuracy. The instrument is fully automated through computer interface operation, including control, data acquisition and processing, display, and printing output.
This instrument uses the isolated method to test the specific heat capacity of solid (powdered, small pieces or small blocks) metallic and non-metallic materials at low temperatures. It is widely used in manufacturing enterprises, quality inspection departments, universities and research institutes and other scientific research units

2.Technical Parameter.

Parameter Specification
Measurement Temperature Range 0 - 100°C, -40 - 100°C (selectable)
Specific Heat Capacity Range 0.05 - 5 kJ/(kg·K)
Accuracy: ≤1% ±0.002
Sample Size Ø30 × 80 mm
Calorimeter Temp. Resolution 0.001°C
Calorimeter Power Supply Voltage: 0-30V (0.1mV resolution)
Current: 0-1A (0.01mA resolution)
Vacuum System Vacuum level: 0.09 MPa (absolute)
Adiabatic Screens Inner/outer screens: 4-pair differential thermopiles
Temp. resolution: 0.0025°C
Temperature Control Method Constant temperature bath
Control System Fully automated computer-controlled testing
Instrument Power Supply 220V/50Hz
Power consumption < 1 kW
