BGD 513 ISO 2813 ASTM D 523 Basic Glossmeter

I'm Online Chat Now

BGD 513 ISO 2813 ASTM D 523 Basic Glossmeter

BGD 513 ISO 2813 ASTM D 523 Basic Glossmeter
BGD 513 ISO 2813 ASTM D 523 Basic Glossmeter BGD 513 ISO 2813 ASTM D 523 Basic Glossmeter BGD 513 ISO 2813 ASTM D 523 Basic Glossmeter BGD 513 ISO 2813 ASTM D 523 Basic Glossmeter

Large Image :  BGD 513 ISO 2813 ASTM D 523 Basic Glossmeter

Product Details:
Place of Origin: China
Brand Name: Lonroy
Certification: CE ISO ASTM
Model Number: BGD 513
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotaible
Packaging Details: wooden package
Delivery Time: 5-8 work days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 200

BGD 513 ISO 2813 ASTM D 523 Basic Glossmeter

Description
Overall Size(L×W×H),mm: 123mm×38mm×65mm Net Weight,g: 300
Power Supply: DC:1.2~1.5;One AA-size Battery Spot Size: 20mm×10mm
Warranty: 1 Year Certification: Includes Calibration Certification
Highlight:

astm paint testing equipment

,

astm paint testing instruments

BGD 513 ISO 2813 ASTM D 523 Basic Glossmeter

1.Description

BGD 513 Basic Glossmeter uses plastic shell and one-body standard board.It can be used in many fields as below:
All kinds of coating and finishing surfaces,such as paints,varnishes,printing ink,etc.
Decorative materials,such as marble,granite,polishing brick,ceramic tile and so on.
The other kinds of materials and objects,such as plastic,woodenware,paper,etc.

At the same time, it has better characters comparing with old types:
* Small,Smart,Stable.
* Simple to use.
* A single battery only.AA size,Rechargeable or alkaline.
* The knob protector for operating with ease.
Features:
* Conform ISO 2813, ASTM D 523, ASTM D 2457 etc
* Calibrate automatically and operate by one button,simple to use
* One type of design, standard board as base,small size for portable
* Come with blue-tooth and software, convenient to transmit and save datas
* A single battery(AA alkaline or rechargeable)can last 60 hours.
* Protect measuring window by special scratch-resist coatings to avoid scratching by samples.

2.Technical Parameter.

Reading Range 0.0~199.9 GU
Indication Error ≤ 1.2 GU
Zero Error ≤ 0.2 GU
Stability ≤ 0.4 GU
Spot Size 20mm×10mm
Measuring Window Size 30mm×14mm
Incidence Angle 60 Deg.
Volume (L×W×H) 123mm×38mm×65mm
Net Weight 300g
Power Supply DC:1.2~1.5;One AA-size battery
Ordering Information BGD 513/1 Intelligent Glossmeter (0.1 GU)
BGD 513/2 Intelligent Glossmeter (1.0 GU)
