BGD 124 Coating Test Viscometer Viscosity Cup

Description

Capacity:	100ml ±1ml	Inner Diameter:	Φ49.5mm ±0.2mm
Internal Cone Angle:	81° ±15'	Nozzle Length:	4mm ±0.02mm
Certification:	Includes Calibration Certification	Warranty:	1 Year
Highlight:	Coating Test Viscometer Cup , Coating Test Viscosity Cup

BGD 124 Coating Test Viscometer Viscosity Cup

1.Description

It is one of the most widely used viscosity cups in China at present. Designed according to GB/T 1723, it is suitable for measuring the conditioned viscosity of coatings and other related products (the outflow time is not more than 150 seconds). Under certain temperature conditions, measure the time for quantitative specimen to flow out from the hole of specified diameter all the time, expressed in S.

2.Technical Parameter

Capacity	100ml ±1ml
Inner Diameter	Φ49.5mm ±0.2mm
Internal Cone Angle	81° ±15'
Nozzle Length	4mm ±0.02mm
Nozzle Orifice Diameter	Φ4mm ±0.02mm
