Plastic Paper And Paperboard Drop Ball impact Tester 45kg - 75kg Weight

Falling ball impact energy absorption tester Plastic paper and cardboard falling ball impact tester

Step 1 Use
Test all kinds of foam materials, protective film materials and other pulse energy absorption test, using modular selection, to meet the needs of various industries users, covering imported, domestic dynamic sensors, a variety of dynamic high-speed acquisition cards, can be combined to select, flexible and any customer test benchmarking, test results worry free.
Falling ball impact energy absorption tester Plastic paper and cardboard falling ball impact tester
2. Product parameters

Carrier specification: customized according to sample
Steel ball or acrylic ball quality: user specified
Sensor capacity: Refer to the last page for selection
Height control: touch screen servo motor lift
Control mode: touch screen + full computer control
Software acquisition frequency: maximum 128K or 25K optional
Steel ball release: automatic release of vacuum cups or other methods
Machine size: see above table
Working voltage: 220V
