Synchronous Heat Differential Scanning Calorimeter DSC DTA Differential Thermal Analyzer

Synchronous Heat Differential Scanning Calorimeter DSC DTA Differential Thermal Analyzer
Synchronous Heat Differential Scanning Calorimeter DSC DTA Differential Thermal Analyzer Synchronous Heat Differential Scanning Calorimeter DSC DTA Differential Thermal Analyzer

Large Image :  Synchronous Heat Differential Scanning Calorimeter DSC DTA Differential Thermal Analyzer

Product Details:
Place of Origin: China
Brand Name: Lonroy
Model Number: LR-TGA-101
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wooden Package
Delivery Time: 5-8 work days
Supply Ability: 200
Contact Now

Synchronous Heat Differential Scanning Calorimeter DSC DTA Differential Thermal Analyzer

Description
Temperature Range: Room Temperature -1200ºC Heating Rate: 0.1~100ºC/min
DSC Range: 0 ~ + 600mW Constant Temperature Time: 0 ~ 300min
Power Supply: AC220V 50Hz
Highlight:

Synchronous Heat Differential Scanning Calorimeter

,

Differential Scanning Calorimeter 50Hz

,

DTA Differential Thermal Analyzer

DSC Synchronous Plastic Thermogravimetric Analysis Differential Thermal Analyzer



1. Product introduction
Thermogravimetric analysis (TG, TGA) is the study of the thermal stability and composition of materials by observing the change in mass with temperature or time during warming, constant temperature or cooling. It is widely used in research and development, process optimization and quality control in the fields of plastics, rubbers, coatings, pharmaceuticals, catalysts, inorganic materials, metallic materials and composite materials.
Measurement and study of the following properties of materials:
Thermal stability, decomposition processes, adsorption and desorption, oxidation and reduction, quantitative analysis of composition, additives and fillers.


2. Technical parameters

Temperature range room temperature -1200ºC
temperature resolution 0.01ºC
temperature fluctuation ±0.1ºC
Heating rate 0.1~100ºC/min
Temperature control mode PID algorithm control, heating, constant temperature, cooling
Constant temperature time 0 ~ 300min arbitrary setting
Balance measurement range 0.01mg ~ 3g, can be extended to 30g
Program control, realize multi-stage heating control
DSC range 0 ~ + 600mW
DSC resolution 0.001mW
Precision of weighing system 0.01mg
constant temperature time 0 ~ 300min arbitrary setting
Display mode 24bit color, 7 inch LCD touch screen display
Atmosphere device built-in gas flowmeter, including two gas switch and flow size control, atmosphere: inert, oxidizing, reducing, static, dynamic
Software  Intelligent software can automatically record TG curves for data processing and print experimental reports
Curve scanning heating scanning and cooling scanning
Power supply There is an isolation shield between power supply and weighing system to avoid ac interference.
AC220V 50Hz
Operating software  it can switch to meet the application switching test of differential, differential heat, thermogravimetric and synchronous heat
Communication interface USB communication
The computer can draw temperature and TG and DSC curves during the test.



Tag:

Thermogravimetric Analysis Equipment,

TGA Thermogravimetric Analyzer,

Thermo Gravimetric Analyzer
