385nm LED Light Curing Machine UV Ink Dryer 900W 0 - 100mm Adjustable Feed Height

385nm LED Light Curing Machine UV Ink Dryer 900W 0 - 100mm Adjustable Feed Height
385nm LED Light Curing Machine UV Ink Dryer 900W 0 - 100mm Adjustable Feed Height 385nm LED Light Curing Machine UV Ink Dryer 900W 0 - 100mm Adjustable Feed Height 385nm LED Light Curing Machine UV Ink Dryer 900W 0 - 100mm Adjustable Feed Height

Large Image :  385nm LED Light Curing Machine UV Ink Dryer 900W 0 - 100mm Adjustable Feed Height

Product Details:
Place of Origin: China
Brand Name: Lonroy
Model Number: LR-400-LED
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotaible
Packaging Details: wooden package
Delivery Time: 5-8 work days
Supply Ability: 200
Contact Now

385nm LED Light Curing Machine UV Ink Dryer 900W 0 - 100mm Adjustable Feed Height

Description
Size: 1000mm × 610mm × 770mm Voltage: 220V 50-60Hz
Bearing Weight: 5KG Feed Height: 0-100mm Adjustable
Light Power: 800W/ Set Irradiation Area: 350mm×150mm
Highlight:

LED UV Ink Dryer

,

UV Ink Dryer 900W

,

UV Ink Dryer 100mm

UV Curing Machine 385nm LED Light Ink Dryer

Product  Model RX300LED-385
Device characteristics
Outside size		 Size:Length 1000mm × width 610mm × height 770mm
Curing district:410mm
Front-rear length:295mm
Feed height:0-100mm adjustable

Curing Way		 The cure:
1. A set of LED surface light source at the top, illuminating downward.
2. Height adjustable (manual)


Mesh belt		 Material: yellow mesh belt, resistant to ultraviolet and high temperature.Bearing weight: 5KG
Width: 300 mm
Speed: 0 ~ 5m/min



Lamp bead		 Light power: 800W/ set
Band: 385nm(other band can be customized) Life: >;20000H
Working environment temperature: -20ºC ~ 40ºC
Light intensity (1cm distance) : >;700MW /cm2 (EIT reference value)
Radiation energy (when the velocity is 2m/min) : >;2300MJ /cm2 (EIT reference value) irradiation area: 350mm×150mm
Cooling way Air cooling
Case Material Cold plate - baking paint/powder spraying



Function and configuration		 1. Power indicator: 1
2. Start button: 1
3. Stop button: 1
4.LED light switch: 1
5.LED power adjusting knob: 1
6. Speedometer: 1
7.Governor :1

Voltage 220V 50-60Hz
Machine power 900W
Machine color White + brown + black

385nm LED Light Curing Machine UV Ink Dryer 900W 0 - 100mm Adjustable Feed Height 0
