ISO 8295 ASTM D1894 COF Tester Coefficient of Friction Testing Machine

ISO 8295 ASTM D1894 COF Tester Coefficient of Friction Testing Machine

Test Standard: ISO 8295, ASTM D1894, TAPPI T816

1. Product Introduction
The friction coefficient meter is based on GB 10006 national standard, which is professional for measuring the static friction coefficient and dynamic friction coefficient of plastic film and sheet, rubber, paper, cardboard, woven bag, fabric style, communication cable and cable metal composite belt, conveyor belt, wood, coating, brake pads, wipers, shoe materials, tires and other materials when sliding. By measuring the smoothness of the material, the production quality process index of the material can be controlled and adjusted to meet the requirements of product use. In addition, it can also be used to determine the smoothness of cosmetics, eye drops and other daily chemical products.

2. Product characteristics
1. The equipment adopts microcomputer control, test process automation, with menu operation interface, PVC control panel and LCD screen, convenient for users to carry out test operation and data viewing.
2. System accessories are made of well-known manufacturers, stable and reliable performance, high-precision force sensor, to achieve the highest test accuracy: 0.001N
3. No mechanical knob, full digital system, digital correction and zeroing.
4. Specially designed drive system, smooth operation, more accurate test results.
5. The system can simultaneously measure the static friction coefficient and dynamic friction coefficient of the sample.
6. Equipped with a micro printer to automatically print the test report of a single piece or group of samples.
7. The instrument test table and test slider are degaussed and remanent magnetic detection, effectively reducing the system test error.
8. Group data, embedded data statistical analysis function.
9. The instrument interface design is simple, the operation is simpler, easy to use.

3. Technical parameter

Slide size	63×63mm
Slide mass	200±2g
Table size	200×470mm
Total error of force measurement system	less than ±1%
Slider speed	100±10mm/min
Slide stroke	70mm... 150 mm
Force measurement range	0-5N
Power supply	220V, 50HZ
Appearance size	480×320×300mm
Weight	about 20 kg
Standard configuration	host, micro printer, 200g slider

According to the standard: GB1006 standard design and manufacturing, and in line with ISO 8295, ASTM D1894, TAPPI T816
